LED Downlight

LED Downlight DTF Series 3inch-8inch

Model: JST-DTF

Wattage: 10W-50W

LED Chip: Citizen/Cree/Philips3030

Driver Brand: OSRAM/Philips/Lifud

RA: >90

Finish Color: White/Black/Customized

Beam Angle: 60°/90°

Diameter: 110mm-230mm

Cutout: 90mm-210mm

Description

DTF Series are originally researched and developed by JST, Protection class up to IP44, die-casting aluminum housing, baking finished surface, use bright reflective paper, reflectivity> 95%, high-grade frosted glass, light transmittance> 90%, high quality Philips3030 LEDs , with OSRAM/LIFUD/TRIDONIC high quality exterior driver, dimmable, good heat sink, brilliant quality, more than 50,000 hours life span.

Advantages

1. High brightness, Low SDCM﹤3, low light decline

2. High efficacy, high illuminance

3. Glare-free design, perfect light spot and accurate beam angle, make surroundings of comfortable illumination

4. Exterior driver(100-277v input)

5. Refined components and design, guarantee a long life span of over 50,000 hours

Specification
ModelPowerCRICCTPFCurrentInput VoltageBeam AngleDimensionCutout
JST-DTF10W>80/902700K-5000K>0.650.25AAC220-240V60°/90°D145*H69mm125mm
JST-DTF15W>80/902700K-5000K>0.900.35AAC220-240V60°/90°D145*H69mm125mm
JST-DTF20W>80/902700K-5000K>0.900.50AAC220-240V60°/90°D145*H69mm125mm
JST-DTF25W>80/902700K-5000K>0.900.65AAC220-240V60°/90°D190*H186mm165mm
JST-DTF30W>80/902700K-5000K>0.900.75AAC220-240V60°/90°D190*H186mm165mm
JST-DTF40W>80/902700K-5000K>0.901.00AAC220-240V60°/90°D230*H99mm200mm
JST-DTF50W>80/902700K-5000K>0.901.25AAC220-240V60°/90°D230*H99mm200mm
Application

Offices, shopping malls, fashion stores, Stations, supermarkets, exhibitions etc.

LED Downlight DTF Series 3inch-8inch LED Downlight DTF Series 3inch-8inch LED Downlight DTF Series 3inch-8inch
LED Downlight DTF Series 3inch-8inch LED Downlight DTF Series 3inch-8inch LED Downlight DTF Series 3inch-8inch
