Model: JST-HTA
Wattage: 1W/3W/7W
LED Chip: OSRAM3030/CREE
Driver Brand: OSRAM/Philips/Lifud
RA: ＞90
Finish Color: White/Black/Customized
Beam Angle: 10°/15°/24°/36°
Diameter: 35mm/55mm
Cutout: 30mm/50mm
Mini downlight series were designed by well-known lighting designers according to the deep anti-glare lighting perfermance and applacation which could archieve UGR<10. Modular design, quickly assemble and disassemble. Front maintenance. Different reflector shapes for options. The shape for fittings include Round, Square, Fixed, Gimbal, Trimless.
· High quality CITIZEN COB, CRI>90, SDCM<3
· Anti-glare design with various free replacement accessories
· Triac, 0-10V and DALI dimming are available
· Modularity structure, easier to assemble, install and disassemble, no damage to the ceiling floor
· Family structure appearance design to meet with the uniform aesthetic requirement
| Model | Power | CRI | CCT | PF | Current | Input Voltage | Beam Angle | Dimension | Cutout |
| JST-HTA-F | 1W | >80/90 | 2700K-5000K | >0.65 | 0.30A | AC220-240V | 10°/15°/24°/36° | D35*H45mm | 30mm |
| JST-HTA-F | 3W | >80/90 | 2700K-5000K | >0.90 | 0.60A | AC220-240V | 10°/15°/24°/36° | D35*H45mm | 30mm |
| JST-HTA-F | 7W | >80/90 | 2700K-5000K | >0.90 | 0.65A | AC220-240V | 10°/15°/24°/36° | D55*H61mm | 50mm |
| JST-HTA-R | 1W | >80/90 | 2700K-5000K | >0.90 | 0.75A | AC220-240V | 10°/15°/24°/36° | D35*H45mm | 30mm |
| JST-HTA-R | 3W | >80/90 | 2700K-5000K | >0.90 | 1.00A | AC220-240V | 10°/15°/24°/36° | D35*H45mm | 30mm |
| JST-HTA-R | 7W | >80/90 | 2700K-5000K | >0.90 | 1.25A | AC220-240V | 10°/15°/24°/36° | D55*H61mm | 50mm |
Hotels, Villas, Cludes, Cinemas, Offices, resturants, Fashion stores, Stations, Shopping malls, Supermarkets etc.
