LED Hotel Downlight

LED Hotel Downlight HTC Series 7-40W

Model: JST-HTC

Wattage: 7W-40W

LED Chip: CREE/Citizen

Driver Brand: OSRAM/Philips/Lifud

RA: >90

Finish Color: White/Black/Customized

Beam Angle: 15°/24°/38°

Diameter: 70mm-170mm

Cutout: 55mm-150mm


Description

LED Hotel Downlight series were designed by well-known lighting designers according to the deep anti-glare lighting perfermance and applacation which could archieve UGR<10. Modular design, quickly assemble and disassemble. Front maintenance. Different reflector shapes for options. The shape for fittings include Round, Square, Fixed, Gimbal, Trimless.

Advantages

· High quality CITIZEN COB, CRI>90, SDCM<3

· Anti-glare design with various free replacement accessories

· Triac, 0-10V and DALI dimming are available

· Modularity structure, easier to assemble, install and disassemble, no damage to the ceiling floor

· Family structure appearance design to meet with the uniform aesthetic requirement


Specification
ModelPowerCRICCTPFCurrentInput VoltageBeam AngleDimensionCutout
JST-HTC7W>80/902700K-5000K>0.900.15AAC220-240V15°/24°/38°D70*H80mm55mm
JST-HTC12W>80/902700K-5000K>0.900.30AAC220-240V15°/24°/38°D85*H105mm75mm
JST-HTC20W>80/902700K-5000K>0.900.50AAC220-240V15°/24°/38°D110*H130mm95mm
JST-HTC30W>80/902700K-5000K>0.900.75AAC220-240V15°/24°/38°D140*H150mm125mm
JST-HTC40W>80/902700K-5000K>0.901.00AAC220-240V15°/24°/38°D170*H180mm150mm
Application

Fashion stores, Stations, Hotels, Offices, Shopping malls, Clubs, Supermarkets etc.

LED Hotel Downlight HTC Series 7-40W LED Hotel Downlight HTC Series 7-40W LED Hotel Downlight HTC Series 7-40W
LED Hotel Downlight HTC Series 7-40W LED Hotel Downlight HTC Series 7-40W LED Hotel Downlight HTC Series 7-40W
